TXA200 Intel I350 Dual Port RJ45 1000Mb / s Network Card PCI-E 4X Gigabit Server Network Card

• Full Duplex/Half Duplex: Supports both full duplex and half duplex operations at all speeds
• Auto-Negotiation: Automatically negotiates between full duplex and half duplex operations, as well as between speeds of 10Mb/s, 100Mb/s, and 1000Mb/s in full duplex mode
• Data Rates: Each port supports 1000Mb/s, 100Mb/s, and 10Mb/s in simplex mode. In full duplex mode, each port supports 2000Mb/s and 20Mb/s
• Cable and Operating Distance: Supports maximum distances of 50m for Category 3, 4, and 5 for 10Base-T, Category 5 for 100Base-Tx, and Category 5E for 1000Base-T. The theoretical distance is defined as half the distance specified in the IEEE 802.3 standard
• Watchdog Timer Interval (Software Programmable): Maximum interval of 3,276,800 milliseconds (3,276.8 seconds) and minimum interval of 100 milliseconds (0.1 second). The watchdog timer interval is calculated using the formula: WDT interval = (2^wdt_interval_parameter) * 0.1 seconds, where the parameter wdt_interval_parameter ranges from 0 to 15

Specifications:

• Model: TXA200
• Chipset: Intel 350AM2
• Ports: 2 x RJ45 interfaces
• Standards: Gigabit Ethernet, 1000Base-T, Fast Ethernet, 100Base-TX, Ethernet, 10Base-T
• Interface: PCI Express 4x
• LED Indicators: 4 LEDs for 10/100/1000Mb (link/act)
• Supported Operating Systems: Windows, Linux, FreeBSD, VMware
• Operating Temperature: 0°C to 55°C
• Relative Humidity: 10% to 90% (non-condensing)
• Storage Temperature: -0°C to 80°C
• Relative Humidity (Storage): 5% to 90% (non-condensing)
